Product Description

Automatic carton box packing machine
Automatic carton box packing machine
WB-120WZ High speed and economical
Details Images
Automatic cartoning system
Cartoning mechanism detail
Cartoning control section
cartoning machine with cover
Cartoning machine with safety cover open
Cartoning machine with safety cover closed
WB-80WZ premium version is suitable for a variety of bottles
Premium version cartoning machine
Bottle feeder interface
Bottle feeding conveyor details
Sample
Carton box samples
Sample carton box type A
Sample carton box type B
Sample carton box type C
Sample carton box type D
Usage:

This machine is suitable for Gorilla bottle, eye drops bottles, food, soap sachet and other similar items of automatic cartoning.

Performance feature:
  • We use high-quality stainless steel to make machine shell, the working surface closed by the plexiglass doors and windows, in strict accordance with the "GMP" standard to be innovative design.
  • With no leaflet automatic rejection function; automatically stop when product into carton is not in place or no carton.
  • Easy to replace the different specifications of the product.
  • PLC control system, color touch screen display, the machine has an automatic count, fault alarm function.
Model WB-120WZ
Capacity 100-120 cartons/min
Power supply 1ph, 220V/3ph, 380V, 50/60Hz
Main motor power 2.5 KW
Gas consumption 5-20L/min (Pressure 0.6Mpa)
Press air 0.5-0.8 Mpa
Carton paper 250-300g (white card) or 300-350g (gray card)
Carton Specification L 45-85mm x W 28-53mm x H 28-53mm
Instruction book Folding range Customized
The number of folding 1-4
Net weight About 1000kg
Overall Dimension L3500xW1100xH1600mm
Machine details
1
Bottle feeding table
connect with filling machine
2
Belt conveyor
transfer bottle from vertical to he horizontal/lying
3
Instruction feeder
Size can be adjusted
Bottle feeding system
Conveyor process line
Instruction leaflet feeding system
4
Carton feeder
Size can be adjusted
5
Push bottle into carton box
with Instruction
6
Fold and seal the carton
Final boxing packaging stage
Carton feeder mechanism
Bottle push device
Flap folding unit
Touch screen display & finish sample
PLC touch panel display
Finished cartoned bottle sample
automatic filling capping + labeling + cartoning line
Automatic packaging production line layout
Related Machines
Automatic filling and capping machine
Automatic filling and capping machine
WB-TB200 automatic sleeve label shrink machine
Sleeve label machine
Shrink tunnel system
WB-MDJ16/20/30 palletizer robot
Palletizing robot arm
Palletizer robot process
Stacking and packaging system
Company introduction
Company office and plant facade
Research development department
Manufacturing workshop floor
CNC machinery unit
Assembly process standard line
Product quality control station
Finished machinery showroom
Global certificates and achievements
Frequently Asked Questions (FAQ)
What products is this automatic cartoning machine suitable for?
The machine is highly versatile and designed for Gorilla bottles, eye drops bottles, food, soap sachets, and other similar items suitable for automatic carton packaging.
What is the production capacity of the WB-120WZ model?
The WB-120WZ model offers a high-speed capacity of 100 to 120 cartons per minute, making it both highly efficient and economical for production lines.
Does the machine comply with industry manufacturing standards?
Yes. The machine shell is made from high-quality stainless steel and features closed working surfaces with plexiglass windows, designed in strict accordance with standard GMP manufacturing parameters.
What happens if a product is misplaced or a carton is missing?
The machine features an automatic rejection function if a leaflet is missing. It will also automatically stop running if the product is not correctly placed inside the carton or if there is no carton available.
How easy is it to change product specifications on this machine?
It is designed for high flexibility, allowing operators to easily replace and adjust specifications to adapt to different product sizes and requirements.
What kind of control system does it use?
The machine incorporates a reliable PLC control system with a color touch screen display interface. It comes equipped with automatic cycle counting and fault diagnostic alarm indicators.
